Home Ugoos Products Ugoos AM6B Plus 2021

Ugoos AM6B Plus 2021

DESCRIPTION SPECIFICATION DOWNLOADS (5)

Ugoos AM6B Plus 2021

Ugoos Brand AM6B Plus with 4Gb LPDDR 4 & 32Gb Storage. Android 9.0 Amlogic S922XJ Smart TV Box is available for order.

Description:

AM6B Plus is a brand new remastered version of 2020 successor AM6 Plus with SoC Amlogic S922XJ, WiFi 6 module, and other improvements.

AM6 Plus gets USB 3.0 Fast USB, Bluetooth 5.0, WIFI 5.0/2.4 GHz with MIMO RSDB Technology Support, and the whole bunch of brand unique Ugoos Settings on board.

Device comes with OTA updater, so you no need to update firmware manually.

Hardware Spec:

Hardware Specs:
Operation System	Android 9.0
Language	English, Chinese ...Multi-Language support
CPU	Amlogic S922XJ with 12nm，Quad core ARM Cortex-A73 and dual-core ARM Cortex-A53 CPU
GPU	ARM Mali TM-G52 MP6(6ppc)
SDRAM	LPDDR4 4GB
Storage Capacity (Flash)	32GB （EMMC）
WIFI	2.4G+5G The wireless module complies with IEEE 802.11 a/b/g/n/ac/ax 2x2 MIMO standard.
Bluetooth	Bluetooth 5.0 with LE technology
The Extended Storage	TF Card, up to 32GB (SD2.X,SD3.X,SD4.X, eMMC ver5.0)
Power Supply	DC 12V/2A
HDR	Support
Interfaces:
HDMI Output	HDMI(2.1 and 2.0 ) to support maximum 4K@60fps output(HDCP2.2)
USB Port	1USB 3.0 Fast Speed, 3USB 2.0 Host
Optical Output	1*SPDIF
Led Work Light	Support
Network	1*RJ45 1000M (1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII interface)
Power Supply	1*DC Jack
Media Parameter:
Audio Container	MP3,AAC,WMA,RM,FLAC,OGG
Audio Out	Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing I2S audio interface supporting 2-channel input and 8-channel (7.1) output Built-in serial digital audio SPDIF/IEC958 output and PCM input/output Built-in stereo audio DAC, Stereo digital microphone PDM input Support concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
Video CODEC	VP9 Profile-2 up to 4Kx2K@60fps H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps AVS2-P2 Profile up to 4Kx2K@60fps H.264 AVC HP@L5.1 up to 4Kx2K@30fps H.264 MVC up to 1080P@60fps MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) WMV/VC-1 SP/MP/AP up to 1080P@60fps AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) RealVideo 8/9/10 up to 1080P@60fps Multiple language and multiple format sub-title video support MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) Supports JPEG thumbnail, scaling, rotation and transition effects o Supports .mkv,.wmv,.mpg, .mpeg, .dat, .avi, .mov, .iso, .mp4, .rm and *.jpg file formats
Software Extension	Support Google Play & APK install
DLNA, Miracast Protocol	Support DLNA, Miracast Protocol
Remote Control	BT remote with Voice+Gyro
IM Software	Support Skype/QQ/MSN/GTALK (Depends on APK ）
Office Software	WORD/EXCEL/PDF(Depends on APK install)
Other Parameters:
Humidity Environment	5%-90%(No condensation）
Certificate	CE, FCC
Package:
Dimensions	11711718.5mm
Net Weight	300g
Gift Box Size	16216280mm

Downloads:

Android 9 firmware V. 0.5.4n for AM6 Family

- add new ddr chip models support

2024-09-25 07:08:35

Download 573,7Mb

Android 9 firmware V. 0.5.4 for AM6 Family

1. Lots of video codec fixes
2. Removed video codec fixes setting
3. HDMI CEC improvements
4. Fixed system crash when pressing Menu frequently
5. Fixed DTS-HD audio passthrough for some audio receivers
6. Fixed issue with no sound after high resolution PCM audio playback
7. Removed HDR to SDR and SDR to HDR settings
8. Added HDR policy setting
9. Added new option: enhanced HDR to SDR (only for AM6+)
10. Fixed problem when automatic frame rate function not available after boot
11. Fixes of automatic frame rate function for Dolby Vision
12. Improved video size detection for system automatic frame rate function
13. Reformed automatic frame rate settings
14. Added new option for changing resolution by AFR_CALC without enabling main setting
15. Fixed button manager issue for some remote controllers
16. Fixed playback pause when using OK button on Bluetooth remote controller
17. Fixed no sound in GeForce Now application for Bluetooth devices (need re-pair)
18. Added key layout for G20 BTS PRO
19. Added USearch application
20. Added UPlayer application with Dolby Vision support
21. Changed Google application to version 3.7.0
22. New CoreELEC build
23. Magisk updated
24. Changed LED indication:
     - active mode: yellow for AM6, magenta for X2/X3 (flashing when remote control buttons are pressed)
     - sleep mode: green for AM6, blue for X2/X3
     - hibernation: red
25. Many other changes for system stability

2022-10-14 11:14:00

Download 615 MB

Android 9 firmware V. 0.4.2 for AM6 Family

Changes' announce in coming v.0.4.2

1. Fixed Magisk update process
2. Fixed option of disabling auto power-on for new devices
3. Few system bug fixes

2022-08-17 08:37:46

Download 609Mb

zip

Android 9 firmware V. 0.4.1 for AM6B full OTA

Full OTA file for Ugoos AM6B
Dualboot firmware is not available for AM6B, for now. Will be available in separate release ASAP.

2021-07-26 13:27:01

Download 650 Mb

zip

Android 9 firmware V. 0.4.1 for AM6B IMG File

IMG File for AM6B
Dualboot firmware is not available for AM6B, for now. Will be available in separate release ASAP.

2021-07-26 13:25:23

Download 570.5 Mb
