| Hardware Specs: |
| Operation System |
Android 4.4/5.1 (Linux Ubuntu or dualboot for option) |
| Language |
Chinese,English...Multi-Language support |
| Chipset |
RK3288 28nm Cortex-A17 Quad core 1.8ghz |
| GPU |
Quad-Core Mali-T764 3D GPU Support OpenGL ES1.1/2.0/3.0, OpenVG1.1, OpenCL1.1 and Renderscript , Directx11, 2D GPU support 8Kx8K input，4Kx4Koutput |
| SDRAM |
DDR3 2GB (optional:1GB) |
| Nand Flash |
8GB Nand Flash(optional:16GB/32GB) |
| Storage Extension |
Support Micro SD(TF) , Up to 32GB |
| Network |
2.4GHz/5GHz WiFi 802.11 b/g/n and 802.11 a/c, Bluetooth 4.0. |
| Power Supply |
DC 5V/2.5A |
| Interface: |
| HDMI |
1xHDMI Out (A type Female), HDMI2.0, Support 4K×2K decode output |
| USB Port |
2 x USB Host |
| Card Reader |
1 x Micro SD card (MMC card) reader |
| AV Out |
1 x 3.5mm Headphone Jack |
| Power Supply |
1 x Micro USB |
| Antenna |
External DualBand WiFi antenna |
| Media Parameter: |
| Audio Container: |
Support MP1、MP2、MP3、WMA、WAV、OGG、OGA、APE、FLAC、AAC、M4A、3GPP…etc Audio formats.Muliti -EQ mode，Support Synchronized lyrics and full-page lyric display. |
| Audio Out |
HDMI Data Output |
| Video Decoder |
MPEG-1, MPEG-2, MPEG-4,H.263, H.264, AVS, VC-1, |
Full video format decoding support. Support H.265 hardware decoding. Support format MPEG-1, MPEG-2, MPEG-4,H.263, H.264, AVS, VC-1,
RV, VP6/VP8, Sorenson Spark, MVC |
| Video Encoder |
H.264，H.265,VP8，MVC(1080P) |
| Resolution |
HDMI output： Support 4Kx2K ( 3840*2160) |
| H.264, H265 Data Rate: |
Up to 60Mbps |
| Image Browser |
Support JPG、JPEG、BMP、GIF、PNG、JFIF…etc photo format.Maximum resolution up to 8192x8192. |
| Text-Reading |
Support TXT、LRC、PDF、Html、Htm、EPUB…etc formats(Depends on APK install)。 |
| Software Extension |
Support Google Play APK install |
| DLNA,Wimo Protocol |
Support DLNA,Wimo Protocol |
| Remote Control |
Support Smart phone remote control、2.4GHZ wireless air mouse/Remote controller. |
| IM Software |
Support Skype/QQ/MSN/GTALK (Depends on APK install) |
| Office Software |
WORD/EXCEL/PDF(Depends on APK install) |
| Certificate |
CE |
| Others Parameters: |
| Operationg Temperature: |
-10~40℃ |
| Storage Temperature: |
-20~50℃ |
| Humidity Environment |
5%-90%(No condensation) |
| Package: |
| Dimension |
107*58*18mm |
| Net Weight |
95gm |
| Carton Box Size |
|
| Gift Box Size |
150*100*85mm |
| Gross weight |
420gm |
